Sunday, May 18, 2014

The CW Morgan readies for her 38th Voyage



from 1962

































all photos courtesy Muffy Aldrich



The CW Morgan left Mystic Seaport yesterday, May 17, for the first time since 1941. She was towed to City Pier in New London for her final fitting out. Here are a few photos of her preparations from about a month ago, when her spars were lifted in. These photos were taken by Muffy Aldrich and first appeared on her very cool blog 'The Daily Prep'. Thanks, Muffy.
Today I have been gathering pics of the Morgan's departure yesterday and should get them up in a day or two...stay tuned.

Here's a bit from Mystic on the Morgan's captain Kip Files for the 38th Voyage:
     As the owner and captain of the 132-foot, three-masted schooner Victory Chimes out of Rockland, Files is no stranger to sailing large ships without an engine. He is also the primary captain of the 207-foot barque Elissa, owned and operated by the Galveston Historical Foundation and Texas Seaport Museum. Files holds a U.S. Coast Guard Master Ocean License for Inspected Passenger Vessels of up to 1,600 Gross Tons. He has been a master of traditional sailing vessels since 1978. He also served on the boards of Tall Ships America (formerly the American Sail Training Association) and the Ocean Classroom Foundation.

    “There are very few people in the world with the knowledge and experience of traditional square-rigged sailing necessary to do this job. Kip is one of those people and we are confident we have found the right person to lead the ship on her 38th Voyage,” said Steve White, president of Mystic Seaport.

copyright Thomas Armstrong

Sunday, November 24, 2013

Lowell's Boat Shop Launches; Alexandria Seaport Update

Lowell's Launch












Photos Courtesy Lowell's Boat Shop

Alexandria Update



Anthony is cleaning up a few details.  All the frames and the inwales are installed and the interior is painted.  The molds have been replaced by 3 cross-spalls to hold the shape of the boat.


 With the seat risers and outwales installed, the boat has enough strength to maintain shape without the cross-spalls.  The centerboard trunk is now installed.  Notice one of the bolts extending through the centerboard trunk and the keel is still visible before being cut flush.



The ceiling and mast step are installed and the thwarts are being installed.  Notice the notch in the centerboard trunk; a thwart will be installed there.



Work proceeds from stem to stern.  All of the thwarts are in place waiting for the steam bent frames that will support them.


 After harpooning a whale, the harpoon line went through the fairlead atop the stem.


View aft -- The loggerhead, mast crutch (for the lowered mast), rudder, tiller mount and aft lifting eye are in place. The loggerhead (big round thing) was used to control the harpoon line when the harpoon was in the whale.  The number of wraps around the loggerhead depended on the whale.  It was essentially a friction brake and a bucket of water was kept nearby to cool it when it began to smoke.



View forward – The notch to hold the harpooner’s leg, the line to support the harpooner, the forward lifting eye, the harpoon rack, and the safety fairleads are in place.  The safety fairleads were safety devices that the crew hoped would catch the harpoon line if it got out of the fairlead on the stem – otherwise a loose harpoon line could crush and kill them.


Installing the mast partner.  These boats were sailed and rowed.  When chasing a whale, the mast was lowered.  To raise the mast safely (remember they were in the middle of the ocean) the bottom of the mast was captured in the hinged mast partner and the foot of the mast was guided down into the mast step by the sloped ramp just forward of the mast step and partner.  Notice the steam bent frames supporting the thwarts and the mast partner.


This is the rod used to raise and lower the centerboard.  Notice the fill pieces used to level the thwarts where the crew sits.  The steam bent frames that support the thwarts are on top, hence the need to level.  Note the plugs glued into the countersink holes for the screws holding the leveling pieces in place.  They will be cut off and sanded flush prior to painting.  The wooden cleat will be installed elsewhere.

Captions and Photos courtesy Alexandria Seaport



Jack Crawford at the Alexandria Seaport Foundation recently sent me some photos of their build in progress. Jack reports they are nearly finished with their build. He adds that they have been taking their time with it, savoring it. Understandable, and laudible. Looks as though they have been doing a great job. Thanks for the update, Jack, and we'll look forward to the launch!

On the subject of launches, Graham McKay at Lowell's Boat Shop sent me photos of their launch on October 6. No captions but they're not needed, the photos are self explanatory. Looks like Graham at the helm and volunteers and apprentices providing the muscle. Lovely boat, congratulations to Lowell's! Graham says they will be building the sail rig over the winter, looking forward to the Morgan's 38th voyage.


Copyright Thomas Armstrong via Whaleboats for the CW Morgan

Wednesday, July 31, 2013

Alexandria Seaport weighs in


"Lofting -- Boat designs are often shared (recorded, sold) as a Table of Offsets, a matrix of numbers on regular paper.  In lofting, the offsets (numbers) are used to draw full size lines on thin plywood showing the exact shapes of key features of the boat to be built.


 Molds -- They define and support the shape of the boat while it is built. Note that we are one of two (Gannon & Benjamin being the other) building upside down. We generally prefer this method and are accustomed to it.  The other way to build this boat is right-side-up using hanging molds.


 Spiling -- A temporary template is clamped in the location of the next plank and it is marked to show the exact shape needed for the next plank.  The marks on the template are transferred to the material for the next plank to accurately define the shape of that plank.


Getting out a plank -- Nails are hammered into Maine cedar(bark still on it) for the next plank at the points transferred from the template.  A flexible wood batten is then held against the nails to draw a smooth line along the marked points.  This line shows where to cut the correct shape for the next plank.


 Progress -- Preparing to install the 5th of 8 planks.


 Almost finished planking -- Only one more to go.


Steaming the Inwale -- The inwale is steamed and bent on the outside of the boat while the molds are still in place, in essence using the boat as a bending jig. After the frames are installed and the molds are removed, the shaped inwale will be installed inside the boat.


Steam Bending the Frames -- Steamed white oak is flexible while still hot, and clamping it to a purpose-built jig allows it to cool and take the shape of the frames.


 Installing frames – note that many of the molds have been removed to make room for the frames and the workers installing them – Rob is under the boat setting screws into the frame held in place by Larry and Anthony.


All photos and captions courtesy Alexandria Seaport Foundation


Jack Crawford at the Alexandria Seaport was kind enough to send me an update on the progress of their whaleboat build. One of the last groups to join the project, they are making fine progress. See for yourself. Here's what Jack has to say about their effort and organization, thanks, Jack:

"The Alexandria Seaport Foundation in Alexandria, Virginia, is building a whaleboat for the CHARLES W MORGAN in their boat building shop on the Potomac River in Old Town.  Through the building and use of traditional wooden boats ASF helps young people turn their lives around and provides families, community groups and schools with meaningful educational, social and recreational experiences. The opportunity to build this whaleboat to the original design is a natural fit for ASF.  The project is a joint effort between the ASF volunteers and apprentices.  Boat building is an integral component of the training for the ASF apprentice program, and the volunteers provide expertise, knowledge and mentoring for the apprentices.

ASF looks forward to joining the other boats and the organizations building them to celebrate the building of this little fleet and, of course, the CHARLES W MORGAN. "


posted by Thomas Armstrong via Whaleboats for the CW Morgan, all rights reserved.

Sunday, July 28, 2013

HUZZAH! CW Morgan is launched

The Whaleboats dance and parade


Six whaleboats from the project were present for the launch. Front row l to r: The Apprenticeshop, Great Lakes Boat Building School and Gannon & Benjamin. Back row l to r: Rocking the Boat, Independence Seaport Museum and Independence Seaport Museum. There was also a seventh boat, from the Mystic Collection, built by Willits and Walt Ansel in 2002.

photo courtesy Wen Byar



Speaking of the Independence Seaport, here are volunteers John Schwarzenbach and Wen Byar, along with CEO John Brady.



Here's the crew of the Great Lakes boat ready to shove off.



Geoff McKonly, formerly of Rocking the Boat, was lead builder for their whaleboat. Here he's sending his crew off for the whaleboat parade.



In the foreground, the Apprenticeshop boat joins the two whaleboats from the ISM.



Rocking the Boat and Great Lakes dancing.



RTB and ISM have a dance.



Here's the boat from Mystic built by Willits and Walt Ansel in 2002.



The Mystic boat led the other five in a 'parade' to the 'Morgan' and back.



Brady et al en route.



The hardy crew of the Apprenticeshop boat. She was sailed and rowed from Rockland ME to Mystic.


The Ceremony




Just prior to the ceremonies I had a sail in the catboat 'Breck Marshall'. Here we see the 'Morgan' and 'Sabino' from the water.



Stage set for the beginning of the proceedings. How massive she is.



Seated just behind the 'Morgan' are the VIP's, and yes, it was hot!



Ric Burns gave the the keynote address, and as I'd expected, it was eloquent and spot on.
to his left is Steve White, President of Mystic Seaport. To the extreme right is Sarah Bullard, a descendant of CW Morgan.



Senator Richard Blumenthal read the U.S, Senate Resolution he co-crafted commemorating the launch.



Sarah Bullard 'christens' the launch with a bottle filled with waters collected from the seas the 'Morgan' sailed.



As the 'Morgan' is slowly lowered into the water, a fireship behind the 'Sabino' let go her spouts.



A great crowd on the water



And finally, she is in.



Huzzah! and Boom



The red white and blue



The 'Morgan' floats,



though not quite to her lines. She still has to be rigged and the added weight of spars and masts will bring here down to where she should be.


On Monday morning the 'Morgan' was towed a little further out into the Mystic River.

photo courtesy John Brady



All photos Thomas Armstrong unless otherwise noted




The morning was inauspicious. Raining. But by the time we had breakfasted, things were looking up, no rain and clearing skies, as they say, the 'Morgan' is a lucky boat. I was lucky as well, running into Dan McFadden communications director at Mystic as I entered the Seaport. He directed me to the dock alongside the 'LA Dunton' where the whaleboats were asssembling for a parade to the 'Morgan' and back. I rushed over to find all six of the project boats and a Mystic whaleboat rowing around the river prior to assembling for the parade. Evelyn Ansel was calling the shots and announced the beginning of the parade. I moved over to Australia beach to catch them going by. Later, my companions and I took a short cruise on the catboat 'Breck Marshall' to get a closer look at CW and the watercraft invading the Mystic River for the celebration. Magic.
By the time the ceremonies began it was sunny and a bit hot. The affable Steve White, President of Mystic Seaport, opened the proceedings. Speeches ensued, by dignitaries, all quite good, actually, then a prayer, and then we came to the Keynote address by the superb filmmaker Ric Burns. Ric is a bit of an historian on American whaling and his documentary 'Into the Deep' for PBS is must see for anyone remotely interested in American whaling, or our history in general. His remarks were cogent and perceptive and a coda to the day.
Sarah Bullard christened the 'Morgan'. She is a descendent of Charles W Morgan. The bottle she used to strike the bow was filled water from the North and South Atlantic, the Pacific and Indian Oceans as well as water from New Bedford and Mystic, her original and current homeports with a wee drop of rum added for good luck.
The 38th Voyage:
Beginning in late May of 2014, the 'Morgan' will embark on another voyage. It will be her 38th. She'll first sail south to New London for sail training and seagoing preparations. Upon leaving New London she'll turn upcoast and visit Newport, Vineyard Haven, New Bedford, Provincetown and Boston. The 'Morgan' will then return to Mystic.
According to Dan McFadden at Mystic Seaport, her voyage and subsequent tenure as a exhibit at Mystic revolves around four major themes: The American Sailor as Icon, The influence of different cultures connecting at sea, Whaling as an example of American enterprise and America's changing relationship to the natural world. Dan states "The last is the most significant: whales were hunted almost to extinction. Today America celebrates the whale and works for it's recovery. Where once the 'Charles W Morgan's cargo was oil and bone, today her cargo is knowledge."

 It's my fervent hope that that's true. This massive work of preservation and restoration, involving more than five years and millions of dollars, and including the work done at the various institutions building the whaleboats, is a monument to history, and quite valuable as an artifact. But to fulfill her potential, the 'Morgan' must also become a potent symbol for another kind of preservation, that of not only whales and other cetaceans but for all worldwide fishing stocks and sea life, as well as our seas themselves, all of which are in danger.

Some stats:

The 'Morgan' is 113' long and 27' wide

She displaces 300 tons

She is rigged as a bark

280 frame futtocks were replaced

She has 70 new ceiling planks

168 new hull planks

22 States have contributed materials or expertise to the restoration.

As one speaker during the Launch ceremony quipped, It's all been said but not everyone has had a chance to say it...

I would like to thank all those involved in this tremendous project, the staff at Mystic, the shipwrights and volunteers who've brought this ship back to life, all the folks involved in the whaleboat project. Especially, Steve White for his tenacious commitment to see the project through in financially difficult times,  three generations of the Ansel family for their commitment to preserving maritime knowledge and skills, Dan McFadden for his help and generosity and to John Brady for inviting me to be a part of the project. It has been and continues to be a great honor.


posted by Thomas Armstrong on Whaleboats for the CW Morgan
